Name: 450W 460W Mono Half Cell Solar Panel With Anodized Aluminium Alloy Frame
Brand: Hochiry
SKU: HR450M-144HC
Rating: 5 (181 reviews)

Home > products > Solar PV Panel >

450W 460W Mono Half Cell Solar Panel With Anodized Aluminium Alloy Frame

460W Mono Half Cell Solar Panel

Anodized Frame Solar PV Panel

Monocrystalline Silicon Solar PV Panel

Place of Origin:

CHINA

Brand Name:

Hochiry

Certification:

TUV

Model Number:

HR450M-144HC

Request A Quote

450W 460W Mono Half Cell Solar Panel With Anodized Aluminium Alloy Frame

Product Details

Product Name:

Mono Half Cell Solar Panel

Solar Cell:

9BB MONO 166*83mm

Number Of Cells:

144 (6*24)

Max. Power:

450W 460W

Solar Cells:

Monocrystalline,Polycrystalline,Amorphous Silicon

Frame:

Anodized Aluminium Alloy

Material:

Monocrystalline Silicon

Warranty:

25 Years Output Power Guarantee

Panel Efficiency:

High Efficiency 144cells

Glass:

3.2mm High Transmission Tempered Glass

Panel Dimensions::

2108*1048*35mm

Junction Box::

IP68 Rated, 3 Diodes

Payment & Shipping Terms

Minimum Order Quantity

100PCS

Packaging Details

27pcs/ per pallet 270pcs/ 1*20' container 648pcs/ 1*40' container

Delivery Time

20-25 work days

Payment Terms

T/T, Western Union, MoneyGram

144 Cells Monocrystalline Pv Module 440W 445W For Solar Energy

Get Best Price

PERC 450w Solar Pv Module Monocrystalline Silicon Sunpower Solar Panels

Get Best Price

72 Cells 420W PERC Photovoltaic Solar PV Panel IP68 Anodized

Get Best Price

Monocrystalline Half Cut Solar Panel 580w Photovoltaic Mono Solar Module

Get Best Price

86-180-25320086

info@szhodas.com

86-0755-5320086

Contact Now

Product Description

Hochiry Mono 9BB Panels Solar 450W 460W 144 Cell Mono Half Cell Solar Panel

Model Number:HCR450M-144
Weight:24kg
Size:2115*1052*40mm(Opt)
Junction Box:IP68 Rated
Solar cell: Monocrystalline, PERC,166mm(9BB)
TPT back sheet:White Backsheet
Connector:MC4 Compatible /MC4 EVO2/TS4*
Glass:3.2mm, High Transmission, AR Coated Heat

Products Description

Electrical Characteristics
Module	HCR440W-144 ~ HCR480M-144
Maximum Power (Pmax)	440W	445W	450W	455W	460W	470W	480W
Maximum Power Voltage (Vmp)	40.50V	40.80V	41.00V	41.20V	41.60V	42.10V	42.60V
Maximum Power Current (Imp)	10.86A	10.92A	10.98A	11.04A	11.16A	11.28A	11.40A
Open-circuit Voltage (Voc)	49.00V	49.20V	49.50V	49.80V	50.30V	50.80v	51.30v
Short-circuit Current (Isc)	11.30A	11.36A	11.42A	11.48A	11.60A	11.72A	11.84A
Module Efficiency (%)	19.62%	20.14%	20.37%	20.60%	21.04%	21.79%	22.54%
Power Tolerance	0~+5W
Temperature Coeffcient of Isc	+0.05%/℃
Temperature Coeffcient of Voc	-0.29%/℃
Temperature Coeffcient of Pmax	-0.37%/℃

Product Display

Glass

*Anti-reflective glass

*High-transmittance and low reflection Increase model efficiency

*High mechanical strength

Solar Cell

*High model efficiency up to 20% *High shunt-resistance: adapt the several environmental conditions

*High PID resistant

* Low breakage rate

*Uniform color

Frame

*Optional silvery or black frame

* Tensile Strength Frame

*Boost bearing capability and prolong service life

Junction Box

*Waterproofness Junction Box

*Innovative Full-Glue-Filled Combination of series circuit and parallel circuit, reduced internal power loss Quality diode ensures module running safety

*Heat dissipation

*Long service life

Production & QC

Automatic typesetting machine

After setting up the program according to the requirements of the process drawings, the typesetting machine will automatically

typeset the battery string. High precision, high efficiency, low defect rate

Solar cell Welding

Use automatic welding machine to connect solar cells in series
All the solar cells are made by top class brand, like TW Solar, Longi Solar

Automatic welding

Automatic laying of EVA, backing, automatic cutting of excess backing material 100% automation of the entire production process

100% Cells Sorting

Ensure Colour and Power Difference. Ensure high yields,consistent performance and durability, First of 52 steps strict quality control and inspection process.

Visual Inspection

Through the turning machine, completely inspect the solar panel after lamination, and record the defects and feedback to the

previous process

100% Optimal Testing

Ensure 3% Positive Power Tolerance Comprehensive QC information management system with barcode ID.Quality traceable system in place to allow quality data flow constantly.

Product Details

Product packaging

PACKAGE CONFIGURATION
Container	310W-340W	360W-410W	440W-480W	500W-660W
Pallet	35Pcs	30pcs	27pcs	27pcs
20GP	390Pcs	360pcs	270pcs	180pcs
40GP	924Pcs	840pcs	780pcs	660pcs

Note: The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.
