Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty

Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty

ETFE Layer Solar PV Panel

200w Solar PV Panel

200 Watt Monocrystalline Solar Panel

Place of Origin:

CHINA

Brand Name:

Hochiry

Certification:

TUV

Contact Us

Request A Quote
Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty
Product Details
Product Name:
200w Folding Solar Panel
Single Solar Pannel Size:
280*185mm
Material:
Monocrystalline Silicon
Max. Power:
100W
Folding Method:
4 Folds
Front Materia:
ETFE Antiskid Surface
Warranty:
1 Year
Expanded Size:
390*390*35MM
Max Out Put Power:
18W/24W
Output Port:
18VDC & 2 USB 5V
Payment & Shipping Terms
Minimum Order Quantity
100PCS
Packaging Details
27pcs/ per pallet 270pcs/ 1*20' container 648pcs/ 1*40' container
Delivery Time
20-25 work days
Payment Terms
T/T, Western Union, MoneyGram
RELATED PRODUCTS
Good price 144 Cells Monocrystalline Pv Module 440W 445W For Solar Energy online

144 Cells Monocrystalline Pv Module 440W 445W For Solar Energy

Get Best Price
Good price PERC 450w Solar Pv Module Monocrystalline Silicon Sunpower Solar Panels online

PERC 450w Solar Pv Module Monocrystalline Silicon Sunpower Solar Panels

Get Best Price
Good price 72 Cells 420W PERC Photovoltaic Solar PV Panel IP68 Anodized online

72 Cells 420W PERC Photovoltaic Solar PV Panel IP68 Anodized

Get Best Price
Good price Monocrystalline Half Cut Solar Panel 580w Photovoltaic Mono Solar Module online

Monocrystalline Half Cut Solar Panel 580w Photovoltaic Mono Solar Module

Get Best Price
Contact Us
86-180-25320086
info@szhodas.com
86-0755-5320086
Contact Now
Product Description
Products Description

High Efficiency Folding Bag ETFE Layer 200 W Monocrystalline Foldable Solar Panels

.
Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty 0
Product Paramenters

Engineered with convenience and practicability in mind, HGP, portable solar charger, features portability and

high powerfor easily using outdoor.
Specifications
Component model
HGC-M-4*12.5W
HGC-M-2*40W
HGC-M-8*12.5W
HGC-M-3*40W
Maximum power
50W
80W
100W
120W
Operating voltage(Vmp)
17.8
20.88
17.8
20.88
Curent(lmp)
2.8
3.98
5.62
5.97
Open cicuit voltage(Voc)
21.3
24.64
21.3
24.64
Short-circuit current(Isc)
3.03
4.22
6.07
6.32
Cells Efficiency(%)
18.40%
22.60%
18.40%
22.60%
Operating Temperature(℃):
-40℃~+85℃
Date under standard testing conditions(STC)
1000W/ m2; 1.5Am
Control waterproof
IP 30
Cell brand
MONO
Power temperature coefficient
-0.39%/℃
Vlotage temperature coefficient
-0.29%/℃
Current temperature coefficient
+0.05%/℃
Nominal Operating Cell Temperature
45 ± 2℃
Folding size
355*290*25mm
560*440*15mm
360*295*40mm
560*440*20mm
Weight
2.57kg
1.60kg
4.48kg
2.70kg
Measured at STC Condition: irradiance: 1000W /m2-AM1.5 Spectrum-Temperature: 25℃
Electrical parameters may vary by +-3%
Specifications
Component model
HGC-P-2*55W
HGC-P-4*30W
HGC-M-2*40W
HGC-M-2*40W
Maximum power
110W
120W
Operating voltage(Vmp)
17.8
19.4
Curent(lmp)
6.18
6.18
Open cicuit voltage(Voc)
21
22.9
Short-circuit current(Isc)
6.59
6.59
Cells Efficiency(%)
20.00%
20.00%
Operating Temperature(℃):
-40℃~+70℃
Date under standard testing conditions(STC)
1000W/ m2; 1.5Am
Control waterproof
IP 67
Output power tolerance
± 3℃
Power temperature coefficient
-0.39%/℃
Vlotage temperature coefficient
-0.30%/℃
Current temperature coefficient
+0.039%/℃
Nominal Operating Cell Temperature
45 ± 2℃
Folding size
660*520*15mm
515*395*30mm
Weight
4.30kg
4.36kg
Measured at STC Condition: irradiance: 1000W /m2-AM1.5 Spectrum-Temperature: 25℃
Electrical parameters may vary by +-3%
Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty 1



Sunpower portable solar charger
Multifunctional portable solar charger, high efficiency, we have 2*40w and 3*40w two items, provide free power for charging 12v batteries, for example in vehicles and boats, motorhome, caravan, camping, narrow boat, yacht etc, or any other systems with a 12V battery or battery bank.
Folding ETFE Layer Solar PV Panel 200w Monocrystalline 1 Year Warranty 2

Charging:

Portable solar charging can be used to charge various types of electronic products even when outdoor camping, self-driving Tours, cycling, hiking and other no-electric suppliers are not available.
