Place of Origin:
CHINA
Brand Name:
Hochiry
Certification:
TUV
Model Number:
SR3222
Contact Us
Features:
1.Pure sine wave inverter
2.Built-in MPPT solar charge controller
3.Selectable input voltage range for home use
4.Selectable charging current based on applications
5.Configurable AC/Solar input priority via LCD setting
6.Compatible to mains voltage or generator power
7.Auto restart while AC is recovering
8.Overload and short circuit protection
9.Smart battery charger design for optimized battery performance
10.Cold start function
11.Parallel operation with up to 6 units only available for MPS4K and MPS 5K
|
Model
|
SHMT-3000
|
SHMT-5000
|
|
RATED POWER
|
3000VA/3000W
|
5000VA/5000W
|
|
INPUT
|
||
|
Voltage
|
230 VAC
|
|
|
Selectable Voltage Range
|
170-280 VAC (For Personal Computers)
|
|
|
90-280 VAC (For Home Appliances)
|
||
|
Frequency Range
|
50 Hz/60 Hz (Auto sensing)
|
|
|
OUTPUT
|
||
|
AC Voltage Regulation (Batt. Mode)
|
230VAC ± 5%
|
|
|
Surge Power
|
6000VA
|
10000VA
|
|
Efficiency (Peak) PV to INV.
|
97%
|
|
|
Efficiency (Peak) Battery to INV.
|
94%
|
|
|
Transfer Time
|
10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
|
|
|
Waveform
|
Pure sine wave
|
|
|
BATTERY & AC CHARGER
|
||
|
Battery Voltage
|
24 VDC
|
48 VDC
|
|
Floating Charge Voltage
|
27 VDC
|
54 VDC
|
|
Overcharge Protection
|
33 VDC
|
63 VDC
|
|
Maximum Charge Current
|
60 A
|
60 A
|
|
SOLAR CHARGER
|
||
|
Maximum PV Array Power
|
4000 W
|
|
|
MPPT Range @ Operating Voltage
|
120 ~ 450 VDC
|
|
|
Maximum PV Array Open Circuit Voltage
|
500 VDC
|
|
|
Maximum Charging Current
|
80A
|
|
|
Maximum Efficiency
|
98%
|
|
|
PHYSICAL
|
||
|
Dimension, D x W x H (mm)
|
100 x 300 x 440
|
|
|
Net Weight (kgs)
|
9
|
10
|
|
Communication interface
|
USB/RS232
|
|
|
OPERATING ENVIRONMENT
|
||
|
Humidity
|
5% to 95% Relative Humidity(Non-condensing)
|
|
|
Operating Temperature
|
0°C - 55°C
|
|
|
Storage Temperature
|
-15°C - 60°C
|
|
