Place of Origin:
CHINA
Brand Name:
Hochiry
Certification:
TUV
Model Number:
PV1000
Contact Us
Description:
lDual wall insulation, Electron beam cross-linked
Excellent resistance to U.V., water, ozone, fluids, salt, general weathering
lExcellent resistance to abrasion
Halogen free, flame retardant, low toxicity
Excellent flexibility and stripping performance
High current carrying capacity
TUV and UL approved
|
No. Of cores x Construction
(mm2)
|
Conductor Construction
(n / mm)
|
Conductor No./mm |
Insul.
Thick. (mm)
|
Current Aarring Capacity (A) |
| 1x1.5 | 30/0.25 | 1.58 | 4.9 | 30 |
| 1x2.5 | 50/0.256 | 2.06 | 5.45 | 41 |
| 1x4.0 | 56/0.3 | 2.58 | 6.15 | 55 |
| 1x6 | 84/0.3 |
3.15
|
7.15 | 70 |
| 1x10 | 142/0.3 | 4.0 | 9.05 | 98 |
| 1x16 | 228/0.3 | 5.7 | 10.2 | 132 |
| 1x25 | 361/0.3 | 6.8 | 12.0 | 176 |
| 1x35 | 494/0.3 | 8.8 | 13.8 | 218 |
| 1x50 | 418/0.39 | 10.0 | 16.0 | 280 |
| 1x70 | 589/0.39 | 11.8 | 18.4 | 350 |
| 1x95 | 798/0.39 | 13.8 | 21.3 | 410 |
