Name: Monocrystalline Silicon Solar PV Panel 600w Mono Solar Panels OEM
Brand: Hochiry
SKU: HRC600M-144HC
Rating: 4.5 (172 reviews)

Home > products > Solar PV Panel >

Monocrystalline Silicon Solar PV Panel 600w Mono Solar Panels OEM

Monocrystalline Solar PV Panel

600w Mono Solar Panels

OEM Mono Solar Panels

Place of Origin:

CHINA

Brand Name:

Hochiry

Certification:

TUV

Model Number:

HRC600M-144HC

Request A Quote

Monocrystalline Silicon Solar PV Panel 600w Mono Solar Panels OEM

Product Details

Product Name:

Solar Panels PV Module

Solar Cell:

9BB MONO 210*105mm

Number Of Cells:

60(6*10)Pcs/72(6*12) Pcs/78(6*13) Pcs

Maximum System Voltage:

2000V Solar System

Max. Power:

580watt 600w 605wp

Solar Cells:

Monocrystalline,Polycrystalline,Amorphous Silicon

Frame:

Anodized Aluminium Alloy

Material:

Monocrystalline Silicon

Warranty:

25 Years Output Power Guarantee

Panel Efficiency:

High Efficiency 144cells

Glass:

3.2mm High Transmission Tempered Glass

Size:

2172*1303*35mm

Payment & Shipping Terms

Minimum Order Quantity

100PCS

Packaging Details

27pcs/ per pallet 270pcs/ 1*20' container 648pcs/ 1*40' container

Delivery Time

20-25 work days

Payment Terms

T/T, Western Union, MoneyGram

144 Cells Monocrystalline Pv Module 440W 445W For Solar Energy

Get Best Price

PERC 450w Solar Pv Module Monocrystalline Silicon Sunpower Solar Panels

Get Best Price

72 Cells 420W PERC Photovoltaic Solar PV Panel IP68 Anodized

Get Best Price

Monocrystalline Half Cut Solar Panel 580w Photovoltaic Mono Solar Module

Get Best Price

86-180-25320086

info@szhodas.com

86-0755-5320086

Contact Now

Product Description

Photovoltaic Energy Suppliers High Power Half Cut PV 600w Mono Solar Panels PV Module

Model Number:HCR600M-120HC(OEM with your label)
Weight:30.9kg
Size:2172*1303*35mm(Opt)
Junction Box:IP68 rated, 3 diodes
Solar cell:Monocrystalline, PERC, 210mm
TPT back sheet:White Backsheet
Connector:MC4 Compatible
Glass:3.2mm, High Transparency solar glass

ELECTRICAL DATA(STC)

Model	HCRxxx-120HC(xxx=585~605 in steps of 5W;120cells)
Peak Power Watts-Pmax(Wp)*	585W	590W	595W	600W	605W
Power Output Tolerance-Pmax(W)	0~+5
Maximum Power Voltage-Vmpp(V)	33.8	34.0	34.2	34.4	34.6
Maximum Power Current-Impp(A)	17.31	17.36	17.40	17.45	17.49
Open Circuit Voltage-Voc(V)	40.9	41.1	41.3	41.5	41.7
Short Circuit Current-Isc(A)	18.37	18.42	18.47	18.52	18.57
Module Efficiency (%)	20.7	20.8	21.0	21.2	21.4
STC	Irradiance 1000W/m2, Cell Temperature 25, Air Mass AM1.5

Product Description

ELECTRICAL DATA (STC)580-605W
Peak Power Watts-PMAX (Wp)	580	585	590	595	600
Maximum Power Voltage-VMPP (V)	33.8	34.0	34.2	34.4	34.6
Maximum Power Current-IMPP (A)	17.16	17.21	17.25	17.30	17.34
Open Circuit Voltage-VOC (V)	40.9	41.1	41.3	41.5	41.7
Short Circuit Current-ISC (A)	18.21	18.26	18.31	18.36	18.42
Module Eciency η m (%)	20.5	20.7	20.8	21.0	21.2
Power Tolerance-PMAX (W)	0 ~ +5
NOCT(Nominal Operating Cell Temperature)	43°C (±2°C)
Temperature Coecient of VOC	- 0.25%/°C
Temperature Coecient of ISC	0.04%/°C
STC: Irrdiance 1000W/m2, Cell Temperature 25ºC, Air Mass AM1.5-Measuring tolerance: ±3%

Product Details

Glass by XINYI,SG CNBMAnti-reflective glass

22% Higher Efficiency Cell by  Tier 1 Brand

Frame by Tentop(Black/Silver Optional) 120N Tensile Strength Frame

Waterproof Labels Product by Waterproof Labels Sunway/OEM

Juction Boxes by TL, QC Solar Innovative Full-Glue-Filled IP68 Waterproofness

PV Connector by TL, QC Solar MC4 4mm Qualified cable

Our Factory

Product Packaging

Note: The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing

with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.

Project Case
