Place of Origin:
CHINA
Brand Name:
Hochiry
Certification:
TUV
Model Number:
HR450M-144HC
Contact Us
|
Electrical Parameters
|
||||
|
Model
|
HCR450M-144 ~ HCR480M-144
|
|||
|
Encapsulation
|
Class/Eva/Cell/Eva/Backsheet
|
|||
|
Maximum Power Pmax(W)
|
450
|
460
|
470
|
480
|
|
Maximum Power Voltage(Vmp/V)
|
41.00
|
41.20
|
41.80
|
42.20
|
|
Maximum Power Current(Imp/A)
|
10.98
|
11.10
|
11.22
|
11.34
|
|
Open Circuit Voltage(Voc/V)
|
49.50
|
50.00
|
50.50
|
51.00
|
|
Short Circuit Currrnt(Isc/A)
|
11.42
|
11.54
|
11.60
|
11.79
|
|
Module Efficiency(%)
|
20.37
|
20.82
|
21.27
|
21.73
|
|
Power Tolerance(W)
|
0~+5W
|
|||
|
Temperature Coefficient of Isc(αIsc)
|
+0.059%/℃
|
|||
|
Temperature Coefficient of Voc(βVoc)
|
-0.330%/℃
|
|||
|
Temperature Coefficient of Pmax(γVoc)
|
-0.410%/℃
|
|||
|
STC
|
Irradiance 1000w/㎡, Cell Temperature 25℃, Air Mass 1.5
|
|||
