GJFJV FRP Strength Member Tight-Buffered Distribution Indoor Fiber Optical Cable
GJFJV Multi-Purpose Distribution cable use several 900um flame-retardant tight buffer fiber as optical communication medium, the tight buffer fiber wrapped with a layer of aramid yarn as strength member units, and the cable is completed with a PVC or LSZH(Low smoke, Zero halogen, Flame-retardant) jacket.
Features on Tight-Buffered Distribution Indoor Fiber Optical Cable
1. Excellent stripper ability with tight buffered fiber
2. Excellent flame retardant properties
3. High tensile strength due to aramid strength member
4. Excellent corrosion resistant, waterproof, flame retardant and
5. environmental- friendly properties of the outer sheath
Applications on Tight-Buffered Distribution Indoor Fiber Optical Cable:
Indoor any purpose cable distribution.
Backbone distribution cable in a building.
Multi optical fiber jumper.
Specifications on Tight-Buffered Distribution Indoor Fiber Optical Cable:
1. Excellent stripper ability with tight buffered fiber
2. Excellent flame retardant properties
3. High tensile strength due to aramid strength member
4. Excellent corrosion resistant, waterproof, flame retardant and
5. environmental- friendly properties of the outer sheath
|
No. of cable
|
2
|
||
|
Fiber Model
|
G.657A2
|
||
|
Strength Member
|
Material
|
Aramid yarn
|
|
|
Tight buffer
|
Material
|
PVC
|
|
|
Diameter(±0.06)mm
|
0.9
|
||
|
Thickness(±0.03)mm
|
0.32
|
||
|
Outer Sheath
|
Material
|
LSZH
|
|
|
Thickness(±0.03)mm
|
0.45
|
||
|
Color
|
white
|
||
|
Cable Diameter(±0.2)mm
|
3.0
|
||
|
Cable Weight(±2)kg/km
|
7
|
||
|
Min. bending radius
|
Without Tension
|
10×Cable-φ
|
|
|
Under Maximum Tension
|
20×Cable-φ
|
||
|
Temperature range
(℃) |
Installation
|
-20~+60
|
|
|
Transport&Storage
|
-30~+70
|
||
|
Operation
|
-30~+70
|
||
