Place of Origin:
CHINA
Brand Name:
Hochiry
Certification:
TUV
Model Number:
GF20X
Contact Us
|
Model Number
|
GF20X
|
|
Certification Number
|
TUV: R50348429
|
|
Rated Voltage
|
TUV 1500V ,UL 1000V, CSA 1500V DC
|
|
Temperature Range
|
-40C to +85C
|
|
Safety Class
|
Class II
|
|
Protection Degree
|
IP67
|
|
Wire Size Range
|
4mm2, 12AWG, 1Meter
|
|
Flame Resistance
|
V-0, 5VA
|
|
Waterproof Range
|
Potting Sealant
|
|
Volume Of Silicon Gel
|
24 ml
|
|
Width Of Copper Ribbons
|
Up to 8mm for soldering
|
|
Connection Method
|
Soldering
|
|
Insulation Material
|
PPE+PS/PA
|
|
Contact Material
|
Copper Alloy
|
|
Overall Size
|
10x8x16cm
|
