Name: Lifepo4 Solar Energy System 48v 100ah Battery Module Pack 6000 Times Cycle Life
Brand: Hochiry
SKU: Hochiry
Rating: 4.9 (140 reviews)

Home > products > Lithium Battery Pack >

Lifepo4 Solar Energy System 48v 100ah Battery Module Pack 6000 Times Cycle Life

Lifepo4 48v 100ah Battery

48v 100ah Battery Module Pack

Solar Energy System Battery Lifepo4

Place of Origin:

CHINA

Brand Name:

Hochiry

Certification:

TUV

Request A Quote

Lifepo4 Solar Energy System 48v 100ah Battery Module Pack 6000 Times Cycle Life

Product Details

Product Name:

Rechargeable 48v 100ah Battery

Battery Type:

LiFePO4

Cycle Life:

3000cycle/6000cycle

Protection:

Built-in Smart BMS

Capacity:

50Ah/80ah/100Ah/200Ah

Application:

Solar, Wind, UPS Energy Storage

Communication Port:

RS232, RS485, CAN

Payment & Shipping Terms

Minimum Order Quantity

10PCS

Packaging Details

Product size: 23*12*20cm Manner of packing: Color Box Single weight:3kg QTY / Carton:4 unit / Carton Carton N.W.:15.4kg Carton G.W.:16.2kg Carton Size:49.5cm*46cm*21cm

Delivery Time

10-15 work days

Payment Terms

T/T, Western Union, MoneyGram

Supply Ability

10000 Piece per week

Home Solar Energy System Rack Lifepo4 Battery Module 48V 400Ah 20Kwh 150Kwh

Get Best Price

5U 48V 100Ah Lifepo4 Battery Module For Telecom Base Station

Get Best Price

48V 100AH LiFePO4 Battery Module For Solar / Telecom UPS

Get Best Price

CATL LiFePO4 Lithium Ion Phosphate Battery Cell Telecom Rack Mounted 3U 5Kwh

Get Best Price

86-180-25320086

info@szhodas.com

86-0755-5320086

Contact Now

Product Description

Dyness 48v Battery Lifepo4 10kwh 6000 Times Cycle Life Lifepo4 Module Battery Pack With 10 Years Warranty

Product Features


Energy Cell 25N/37N/50N
Pylontech develop the energy type cells with our own unit design to ensure the high energy density with long cycle life the high

safety standard. Our cell had been widely deployed in the energy storage system, UPS system, logistic vehicles and other areas.


Product Performance1.Compact size for saving space;

90% DOD with more useable capacity;

10+ years technical proven;

Be expandable for need;

Superior low failure rate;

Optimal electricity cost;


Components Included
Pylontech battery bracket;

Power cable,connection cables,parallel cable

Battery breaker;

BMS built in the battery.

LV-HUB Parallel Kit

Multi Battery Piles RS485 Communication Cable Connection Each Communication HUB connects maximum 5 battery string.Each battery pile can configue maximum 8pcs US2000B Plus or 8 pcs US3000.

Specification

Basic Parameters	US2000C	Phantom-S	US3000C
Nominal Voltage (V)	48	48	48
Nominal Capacity (Wh)	2400	2400	3552
Usable Capacity (Wh)	2200	2200	3200
Dimension (mm)	44241089	44044088.5	442420132
Weight (Kg)	24	24	32
Discharge Voltage (V)	45 ~ 53.5	45 ~ 53.5	45-53.5
Charge Voltage (V)	52.5 ~ 53.5	52.5-53.5	52.5-53.5
Charge / Discharge Current (A)	25(Recommend)	25(Recommend)	37 (Recommend)
	50 (Max)	50 (Max)	74 (Max)
	100 (Peak© 15s)	100 (Peak© 15s)	100 (Peak@15s)
Communication Port	RS485, CAN	RS485. CAN	RS485. CAN
Single string quantity(pcs)	16	8	16
Working Temperature/"C	-20~60	-20-60	-20-60
Shelf Temperature/°C	-20-60	-20 〜60	-20-60
Humidity	5%~85%	5%~85%	5%~85%
Altitude (m)	<4000	<4000	<4000
Design life	15+Years (25°C/77°F)	15+Years (25°C/77T)	15+Years (25aC/77T)
Cycle Life	>6000, 25C	>6000, 25 C	>6000, 25C
Authentication Level	UL/IEC62619/CE/UN38.3	IEC62619/CE /UN38.3	IEC62619/CE /UN38.3
