Name: 360KW DC Split Type EV Charging Station IP55 Floor Standing European Standard
Brand: SHENZHEN HODAS TECHNOLOGY COMPANY
SKU: HDS-DC360KW
Price: Negotiable USD
Availability: InStock

Home > products > EV Charging Station >

360KW DC Split Type EV Charging Station IP55 Floor Standing European Standard

360KW EV Charging Station

DC Split Type EV Charging Station

Place of Origin:

CHINA

Brand Name:

Hochiry

Model Number:

HDS-DC360KW

Request A Quote

360KW DC Split Type EV Charging Station IP55 Floor Standing European Standard

Product Details

Products Name:

Fast Electric Car EV Charging Stations

Charging Port::

2 Ports, 1port

Input Power::

380V AC+20%/ 50Hz±5Hz

Rated Current::

360KW

Payment Method::

RFID Card,APP

Protection Level::

IP55

Payment:

Plug&Play/RFID Card/App

Payment & Shipping Terms

32A Level 2 Public Commercial EV Charging Station With OCPP 1.6 Wifi 4G

Get Best Price

360KW DC Split Type EV Charging Station IP55 Floor Standing European Standard

Get Best Price

16A Type 2 Portable Electric Car Charger CCS Combo 2 Fast Charger

Get Best Price

IP66 240V 32 Amp Level 2 Charging Station With 6m Cable

Get Best Price

86-180-25320086

info@szhodas.com

86-0755-5320086

Contact Now

Product Description

360KW DC Split Type European Standard EV Chargers Fast Charging Stations

Main features:

Adopting a nuclear power-grade high-power power module platform, the safety and reliability are higher;
The new high-efficiency three-phase PFC circuit topology is adopted, the power factor is greater than 0.99, and the harmonic distortion rate is ≤5%.
The high-frequency switching power supply module adopts full-bridge phase-shift soft-switching technology, and the execution efficiency is high.
The advanced digital current sharing technology effectively improves the current sharing accuracy and anti-interference; the first module sleep technology and the wheeling technology ensure the high-efficiency operation of the system;
Intelligent charging process control and perfect charging process monitoring and protection, fool-like operation;
A variety of charging methods such as timed charging, quantitative charging, fixed amount charging and automatic charging are available;
Real-time display of information such as the amount of charge, charging time, current electricity price, charging price, and
operating status;
The RS-485 networking communication interface can be reserved, and the optional GPRS networking mode can be provided;
Module hot swap technology makes maintenance more convenient;
Working environment temperature -20+50 °C
Scope of application
Integrated DC charging pile is suitable for urban public charging stations (bus, taxi, official car, sanitation car, logistics
car, etc.) city public charging station (private car, commuter car, bus) cityVarious parking lots in residential areas, shopping plazas, power business places,etc.; intercity highway charging stations, etc.

Datasheet	Model	HDS-DC360KW
Input	Power Supply	3P+N+PE
	Rated Voltage	400V AC
	Rated Current	300A
	Frequency	50/60Hz
Output	Output Voltage	200~1000V DC
	Maximum Current	200A
	Rated Power	120KW
User Interface	Charge Connector	CCS2	CCS2
	Cable Length	5M	5M
	Enclosure	Galvanized steel
	LED Indicator	Green/Yellow/Red
	LCD Display	10'' color touch screen
	RFID Reader	Mifare ISO/IEC 14443 A
	Start Mode	Plug&Play/RFID card/App
	Emergency Stop	Yes
	POS Terminal	Optional
Communication	WiFi	Yes
	Ethernet	Yes
	3G/4G	Yes
	OCPP	OCPP 1.6 JSON (OCPP 2.0 optional)
Electrical Parameter	Efficiency	≥95%
	Power Factor	≥0.99 @ 50%~100% loading
	THD	≤5% @ 50%~100% loading
	Ripple Factor	≤±0.5%
Sefety	Energy Meter	PTB certified	PTB certified
	RCD	Type A
	Ingress Protection	IP54
	Impact Protection	IK08
	Electrical Protection	Over current protection, Residual current protection, Short circuit protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection
	Certification	CE
	Certification Standard	EN/IEC 61851-1: 2017, EN/IEC 61851-23: 2014
	Warranty	2 Years
Environment	Installation	Floor-stand
	Cooling Method	Fan cooling
	Noise	≤60dB
	Work Temperature	-30℃~+50℃
	Work Humidity	5%~95%
	Work Altitude	<2000M
Package	Product Dimension	7505251830MM (WDH)
	Package Dimension	10207452030MM (LWH)
	Net Weight	240KG
	Gross Weight	280KG
	External Package	Wood case
